ScanaQuad Logic Analyzer Pattern Generators – SQ100

ScanaQuad Logic analyzers and ScanaStudio software let you capture digital signals, analyze them in depth or generate test patterns. That will help you get your embedded system up and running, quickly!Capture GenerateScanaQuad Logic analyzer lets you capture, generate or do both simultaneously.Easily debug your serial interface or stimulate your circuit with test patterns and check its response.Protocol TriggerComplex multi-step trigger lets you target precise features of your data, like a specific I2C address or a CAN frame ID.Trigger sequences can even be defined for proprietary protocols!30 Protocols30 protocol decoder scripts are open source and included by default. I2C, SPI, RS232, CAN, 1-WIRE, JTAG, you name it!
