Grundfos Pumps 52722370 115V 1/6HP 1-Speed Bronze Circulator Pump UP43-75BF

Description Circulator Pump Type 1-Speed, Canned Rotor, Large Stator End Connection Flanged x Flanged Overall Dimensions 8-1/2 Inch Length x 6-11/16 Inch Width Flow Rate 0 to 45 GPM Discharge Head 0 to 10.2 Foot Casing Material Bronze Shaft Material Ceramic Impeller Material Composite, PES Impeller Design Closed Warranty 24 Months from the Date of Delivery Shaft Seal Details Aluminum Oxide Ceramic Power Rating 1/6 HP Input Supply Rating 115 Volt AC at 60 Hertz, 1-Phase 2.15 Amp Temperature Rating 36 to 230 Deg F Pressure Rating 145 PSI Motor Type 2-Pole Asynchronous Squirrel-Cage Permanent Split Capacitor Inclusions / Features Carbon Thrust Bearing, Stainless Steel Rotor Can and Bearing Plate, Corrosion Resistant Application Heating System, Hot Domestic Water, Cooling and Air Conditioning System Applicable Standard CSA, UL (Canada and US) Capacitance 10 Microfarad, Voltage Rating 180 Volt Water Density 983.2 Kilogram per Cubic Meter Resources:GRUNDFE00078_11_23_25_27_28_70.pdfGRUNDFE00325_1_2.pdf
